Backlit LED Panel Light
Prev: Side-emitting LED Panel Light Next: IP65 LED Panel Light

Backlit LED Panel Light

Features:
  • Standard Sizes ideal for replacement of troffer lights.
  • Made of Aluminum Frame & PS diffuser & PMMA LED Lens, base 0.25mm thick.
  • Presents even and smooth light effect.
  • Isolated Driver AC85-265V, safe installation.
  • Available function: 0-10V dimmable, Dali-Dimmable. Emergency function.
  • New Erp Directive Compliant.

Specifications:

Model Dimension(mm) Power Lumen Voltage PF CCT RA Beam angle
NR-PLB6060 595*595*30MM 36/40W 90-100lm/w 85-265V PF>0.9/>0.5 3000K/4000K/6000K >80 120°
NR-PLB6060 595*595*30MM 48W 90-100lm/w 85-265V PF>0.9/>0.5 3000K/4000K/6000K >80 120°
NR-PLB30120 295*1195*30MM 36/40W 90-100lm/w 85-265V PF>0.9/>0.5 3000K/4000K/6000K >80 120°
NR-PLB30120 295*1195*30MM 48W 90-100lm/w 85-265V PF>0.9/>0.5 3000K/4000K/6000K >80 120°
NR-PLB60120 595*1195*30MM 72W 90-100lm/w 85-265V PF>0.9/>0.5 3000K/4000K/6000K >80 120°
